LabGear BNT Series Analytical Balances

Product Description

Now in stock!

Free Global Shipping!

Delivery to almost any location worldwide!

Labgear's BNT Series Analytical balance utilizes advanced microcomputer control of an electromagnetic force restoration (EMFR) sensor balance mechanism with for extremely accurate microgram weighing precision, yet priced comparably with the less precise load cell type balances.  The 5” LCD Touchscreen display provides an easy, clear and operator-friendly interface, along with internal calibration and glass draftshield for incredible performance at a reasonable price.

Applications

NIST Videos for 0.0001g Analytical Balance Applictions (Click here to View)

or copy and paste:  https://www.nist.gov/video/use-analytical-balances

Features

• Bright 5"LCD display screen for clear readings,

• All sides glass windshield for maximum accuracy while samples are clearly visible,
• Access through two sides and the top for ease of loading,
• Dynamic temperature compensation,
• Clear and complete operating instructions,
• Filtering adjustable function,
• Auto return to zero function,
• Flexibility of measurement mode and units for a wide range of industries,
• Digital interface for data monitor, second display and controls.

Specifications

• Weighing mechanism:  Electromagnetic force restoration (EMFR)
• Pre-heat time (Typical): ~60 minutes
• Stable time: ~3s
• Operation temperature:  17.5-22.5°C, (64-73°F)
• Atmosphere wave filtering and optimization,
• Adjustable anti-vibration filtering level,
• Tare and back to zero within the whole weighing scope,

• External Calibration Weight included.  A precision calibration weight ideal for the calibration of each model balances is included. The weights meet the OIML (International Organization of Legal Metrology) standard.  Each is made of highly polished and non-magnetic stainless steel with a density of 7.96 kg/dm³.

• Each weight is OIML F1 Grade and comes packaged in a protective screw cap container.

• Overload detection and display,
• Full color 5" LCD touchscreen display,
• RS-232C serial interface,

• Measurement modes:
• Percentage weighing function
• Count weighing function
• Filling weighing function
• Density direct reading
• Bottom weighing function

• Unit of Measure Settings:

  Units	Mark
  gram	g
  Carat	ct
  Ounce	oz
  Troy weight ounce	ozt
  Penny weight	dwt
  grain	GN
  pound	lb
  Newton	N
  Dram	dr
  Taiwan tael	tlT
  Singapore tael	tlS
  Hong Kong tael	tlH
  tola	T
  momme(Japan pearl)	mom
  Kilogram	kg
  Microgram	mg

• Pan diameter:  Φ90mm
• Overall dimensions（LxWxH):  325 X 205 x 305 mm
• Weigh chamber dimensions（LxWxH): 180 x 175 x 200 mm
• Net weight:  6kg
• Adapter power supply:  100-240VAC 50/60Hz (to 15VDC/600mA)
• Certifications:  CE, RoHS, ISO9001
• Warranty:  Two Years

Optional Accessories

• Optional under-hook weighing accessory
• Option to add thermal printer

 LabGear USA BNT Touchscreen Analytical Balance Operators Manual (Click Here to Download)
