Product Description

MRC UT-FLU1A / UT-FLU1B / UT-FLU1C Dual Channel Portable Fluorometers

offer UV, Blue, Red & Green Channel options to deliver fast, on-site fluorescence measurements with two built-in optical channels per model (UV+Blue, Blue+Red, or Blue+Green). A 4.3-inch touchscreen, self-test on startup, on-board standard-curve creation, and automatic data logging make routine assays simple and repeatable. Monochromatic LED excitation with matched emission filters provides stable signal, R² > 0.995 linearity, and <1.5% repeatability for confident quantitation. Export results or print via USB. Accepts cuvettes and fluorescence PCR tubes (0.2 mL / 0.5 mL) to suit benchtop or field workflows. Choose UT-FLU1A for UV-excited dyes (e.g., Hoechst), UT-FLU1B for red-emitting dyes (e.g., Cy5), or UT-FLU1C for green/orange dyes (e.g., Rhodamine/Cy3) alongside a Blue channel for FITC/fluorescein/eGFP.

Applications

Environmental Monitoring & Water Quality

• Rapid screening with fluorescence probes and standard curves for on-site decisions.
• Field-friendly footprint (≈0.4 kg) with USB data export for audit trails.

Biotech & Pharmaceutical QC

• DNA/RNA quantitation and protein assays with repeatable single-pass measurements.
• Built-in methods (dsDNA, RNA, Protein, Oligo, Custom) streamline routine tests.

Food & Beverage QA

• Fluorescence-based checks for process markers and tracer dyes.
• On-board curve storage enables quick lot-to-lot comparisons.

Academic & Core Labs

• Fast training curve from touchscreen; exportable reports for documentation.
• Flexible sample formats: cuvette or 0.2/0.5 mL fluorescence PCR tubes.

Production Process Monitoring

• 3-second single-pass reads support in-process checks and line clearance.
• USB printing for paper records when LIMS access is limited.

For Research Use Only — not for clinical diagnostics.

Features

• Two channels per unit — pick the wavelength pair that matches your dyes and assays (UV+Blue, Blue+Red, or Blue+Green) for best sensitivity and specificity. Choose your model by dye chemistry:
  • UT-FLU1A (UV+Blue): Hoechst, 4-methylumbelliferone, fluorescein/FITC, eGFP, DNA/RNA quant.
  • UT-FLU1B (Blue+Red): FITC/eGFP plus red dyes such as Cy5 and common RNA quant assays.
  • UT-FLU1C (Blue+Green): FITC/eGFP plus orange/green dyes like Rhodamine/Cy3 and RFP.

• Touch-and-measure workflow — self-test on power-up, guided touchscreen menus, and 3-second single-pass measurements reduce operator variability.
• Quantitation you can trust — R² > 0.995 linearity with <1.5% repeatability and stability supports reliable standard curves and trending.
• On-board analytics — create and store onboard curve and calibration standard curves; dedicated modes for dsDNA, RNA, Protein, Oligo, and Custom assays.
• Portable & versatile — uses cuvettes or fluorescence PCR tubes; compact 194 × 155 × 72.5 mm footprint at ≈0.4 kg.
• Data your way — automatic logging with USB export or direct USB printer output for immediate records.
• Kinetic mode: UT-FLU1 series includes continuous (kinetic) detection.

Specifications

• What’s included: Instrument, power adapter, 0.5 mL tube holder, USB stick, user manual.

Documentation

• Operators Manual — UT-FLU1 Series

FAQs

• What’s the difference between UT-FLU1A, UT-FLU1B, and UT-FLU1C?
  Each model has two fixed optical channels: A (UV+Blue), B (Blue+Red), C (Blue+Green). Pick the pair that matches your assay dyes (e.g., Hoechst→A, Cy5→B, Rhodamine/Cy3→C).
• Which sample containers are supported and how much volume is required?
  Cuvettes (≈3 mL) and fluorescence PCR tubes: 0.2 mL (≈0.1 mL sample) and 0.5 mL (≈0.2 mL sample).
• How sensitive is it for nucleic acid quantitation?
  The platform supports dsDNA detection down to ~1 ng/mL with proper standards and protocol.
• Can I store curves and export or print data?
  Yes. Build and store standard curves on the instrument, log data automatically, and export via USB or print to a USB-connected printer.
• Is the instrument intended for clinical diagnostics?
  No. It is designated For Research Use Only (RUO) and not for clinical diagnostic procedures.
• What are the power requirements?
  DC 6–35 V input (external 12 V adapter included; AC100–220V adapter).

Warranty

Warranty is 1 year from purchase date against defects in materials and workmanship. For support, contact Labgear USA with your order number and instrument serial number. Accidental damage, misuse, and consumables are excluded.
